Overview

This high-efficiency micron membrane filter is designed for precise liquid filtration across laboratory, industrial, and chemical processing environments. Engineered with multiple membrane material options and wide pore-size availability, it delivers reliable contaminant removal, stable flow performance, and broad chemical compatibility (pH 1–13).

With its compact construction, hose-barb connection, and robust temperature resistance, this filter offers versatile integration into a variety of liquid-processing systems.

⭐ Key Features

• 🧩 Core Component: Micron membrane
• 🧪 Membrane Materials Available: PP, PES, PVDF, PTFE, N6, N66, CN-CA, GF
• 🔍 Pore Size Options: 0.10 μm, 0.20 μm, 0.45 μm, 0.65 μm
• 🧴 Application: Liquid Filtration
• 🧲 Membrane Base Material: PP
• ⚖️ Weight: 0.3 kg

🌡️ Performance Specifications

• 🔥 Max Working Temperature: 85°C (at P ≤ 0.10 MPa)
• 🌤️ Normal Working Temperature: ≤60°C
• 📏 Filtration Area: 0.1 m² – 0.4 m²
• 🔗 Connection Type: Hose Barb
• 🧫 pH Compatibility: 1–13

📋 Quality Assurance

• 📄 Machinery Test Report: Provided
• 🎥 Video Outgoing Inspection: Provided

🔧 Filtration Media Options

• PP (Polypropylene)
• PES (Polyethersulfone)
• PTFE (Polytetrafluoroethylene)
• Nylon
• PVDF
• GF (Glass Fiber)
• CA–CN (Cellulose Acetate / Cellulose Nitrate)

🏗️ Construction Details

• Cage: Polypropylene (PP)
• Support Layers: Polypropylene (PP)
• Sealing: Thermal-welded for maximum strength and leak prevention

📊 Micron Ratings

PP Membrane

0.1 μm, 0.22 μm, 0.45 μm, 1.0 μm, 3.0 μm, 5.0 μm, 10.0 μm, 20.0 μm, 30.0 μm, 50.0 μm

PES Membrane

0.1 μm, 0.22 μm, 0.45 μm

PTFE Membrane

0.01 μm, 0.02 μm, 0.1 μm, 0.22 μm, 0.45 μm

📋 Applications

• 🎨 Digital Inks & Paints
  Ideal for filtering pigments, solvents, and fine particulate in digital printing and painting workflows.
• 🌬️ Gas / Air Sterile Filtration
  Supports sterile ventilation and contaminant removal for cleanroom and process-air applications.
• 🧪 Laboratory Solutions
  Suitable for buffers, reagents, culture media, and general laboratory liquid filtration.
• 💡 Electronics Industry (Photoresist, Acids, etc.)
  Ensures high-purity filtration of photoresist materials, etching chemicals, and acids used in semiconductor processes.
• ⚗️ Chemical Industry – Corrosive Liquids & Solvents
  Compatible with aggressive chemicals and solvents requiring high-purity, corrosion-resistant filtration.
• 🧫 Biological Applications
  Supports small-volume injections, tissue cultures, and sterile handling in biotech and pharmaceutical environments.
